Pressure Meter with Excel-Formatted Data Logging SD Card

Item #
PM930SD
BUY NOW

The #PM930SD can measure, display and log hydraulic or pneumatic pressure using optional sensors with full-scale ranges from 2 to 400 bar. Choose one or more sensors with the right range(s) for your applications.

  • Sensors are calibrated by a single button press
  • Ten different pressure units are available
  • Min/Max memory + data hold
  • Large backlit LCD
  • Auto power off (can be disabled for data logging)
  • Tripod mount
Specifications
  • Measurement accuracy (excluding sensor error): ±(0.5% of full-scale reading + 1 digit)
  • Pressure unit options: bar, psi, in.Hg, in.H2O, hPA, kPA, kg/cm2, mmHg, meters H2O, atmospheres
  • Pressure sensor input range: 0 to 100mVDC (full-scale)
  • LCD size: 1.5 x 2.0 in. (38 x 52mm)
  • Data logging sampling time: Adjustable from 1 second to 9 hours
  • Auto power off: After 10 minutes of inactivity
  • Operating temperature: 32° to 122°F (0° to 50°C) @<85% RH
  • Weight: 0.77 lb. (350g)
  • Power source: Six "AA" batteries (not included) or optional #AC1 9V AC adaptor
Includes
  • 2GB SD memory card
  • Custom hard plastic carrying case
  • 1-year limited warranty
Dimensions
  • 6.97 x 2.68 x 1.77 in. (177 x 68 x 45mm)
