In stock

Vibration Meter with Excel-Formatted Data Logging SD Card

Item #
VM8205SD

The #VM8205SD can measure and log a machine's acceleration and velocity to determine whether it is running smoothly—typically as part of a preventive maintenance program.

  • Includes the replaceable #P8205SD vibration probe
  • Displays acceleration readings in m/sec2 or ft/sec2 and velocity readings in mm/sec or in./sec
  • The magnetic base facilitates attachment of the probe to metal parts or a machine's housing
  • Large backlit LCD
  • Max/peak/RMS memory + data hold
  • Downloads logs in Excel format
  • Auto power off (can be disabled for data logging)
  • Tripod mount
Specifications
  • Measurement ranges: 0.5 to 199.9 m/sec2 and 2 to 656 ft./sec2 for acceleration; 0.5 to 199.9 mm/sec and 0.02 to 7.87 in./sec for velocity
  • Measurement accuracies: ±(5% of reading + 2 digits) for acceleration; ±(5% of reading + 2 digits) for velocity
  • Measurement resolutions: 0.1 m/sec2, 1 ft./sec2, 0.1m/sec and 0.01 in./sec
  • Data logging sampling time: Adjustable from 1 second to 1 hour
  • LCD size: 2.05 x 1.5 in. (52 x 38mm)
  • Auto power off: After 10 minutes of inactivity
  • Operating temperature: 32° to 122°F (0° to 50°C) @ <85% RH
  • Weight: 1.13 lb. (515g)
  • Power source: Six "AA" batteries (not included) or optional #AC1 9V AC adaptor
Includes
  • #P8205SD vibration probe
  • Magnetic base
  • 2GB SD memory card
  • Custom hard plastic carrying case
  • 1-year limited warranty
Dimensions
  • 7.99 x 2.99 x 1.50 in. (203 x 76 x 38mm)
